Description
Technical Specifications
| Material | SPCC cold rolled steel |
| Surface Treatment | Pickling, degreasing, phosphating, electrostatic spray |
| Product Configuration | 1pc tray, 1bag screw |
| Product Function | Install network equipment, switches, routers, KVM, power amplifiers, computers, patch panels and some standard network equipment |
| Product Standard | Comply with ANSI or EIARS-310-D,DIN41491,PART1, IEC297-2,DIN41494,PART7,GB or T3047.2-92 standard
Compatible with metric ETSI and 19 inch |
| Specifications | 2U to 15U |
| Thickness | 0.0591 in, 0.0315 in(Mounting profile: 1.5 mm, others: 0.8 mm) |
| Product Size | 20.47 in x 15.75 in x 7.87 in(2U:520 mm x 400 mm x 200 mm) to 21.26 in x 29.53 in x 17.72 in(15U:540 mm x 750 mm x 450 mm) |
| Loading Capacity | 110.23 lbs (50 kgs) |
