| Network |
Wired LAN |
| E1 Interface Standard |
Comply with protocol G.703 |
| E1 Interface Rate |
2048 Kbps ± 50ppm |
| Ethernet Interface Rate |
10/100/1000 Mbps half/full duplex auto-negotiation |
| Ethernet Interface Standard |
Compatible with IEEE 802.3, IEEE 802.1Q (VLAN) |
| Power Supply |
AC 180V to 260V; DC -48V; DC +24V |
| Storage Humidity |
5% to 95% (no condensation) |
| Color |
Black |
| Interface Rate |
n*64Kbps ± 50ppm |
| Interface Code |
HDB3 |
| E1 Impedance |
75Ω (unbalanced), 120Ω (balanced) |
| Jitter Tolerance |
In accordance with protocol G.742 and G.823 |
| Allowed Attenuation |
0 dBm to 6 dBm |
| MAC Address Capability |
4096 |
| Connector |
RJ45, supports Auto-MDIX |
| Power Consumption |
≤ 10 W |
| Storage Temperature |
-40°F to 176°F (-40°C to 80°C) |
| Working Humidity |
5% to 95% (no condensation) |
| Working Temperature |
14 °F to 122 °F (-10 °C to 50 °C) |
| Product Size |
8.50 in × 5.51 in × 1.22 in (21.6 cm × 14 cm × 3.1 cm) |
