| Max. LAN Data Rate |
1000 Mbps |
| Wi-Fi Supported Frequency |
2.4G and 5G |
| 2.4G Wi-Fi Transmission Rate |
300 Mbps |
| Standards And Protocols |
Wi-Fi 802.11g, Wi-Fi 802.11b, Wi-Fi 802.11n, Wi-Fi 802.11ac |
| Encryption Type |
WPA2-PSK, WPA2, WPA, WEP, WPA2-Personal |
| Ethernet |
5 × LAN (1000 Mbps) |
| WIFI |
2.4GHz or 5.8GHz IEEE802.11b or g or n or ac |
| Serial Port |
1 × RS232, 1 × RS485 |
| Input/Output |
2 × DI, 1 × DO |
| LAN Ports |
5 |
| Function |
Firewall, QoS, VPN |
| Antenna interface |
5 × SMA (5G or 4G), 2 × WIFI 2.4G, 2 × WIFI 5.8G |
| SIM |
2 x SIM/UIM slot, 1.8V or 3V AUTO detection |
| 5G Wi-Fi Transmission Rate |
867 Mbps |
| Power |
+9V to +32V |
| Serial Port |
1 x RS232, 1 x RS485 |
| SIM Card Slot |
2 |
| Network |
5G or 4G or 3G or 2G |
| Humidity |
<95% No condensation |
| Temperature |
-22 °F to +167 °F (-30 ℃ to +75℃) |
| Dimensions |
7.047 in x 4.843 in x 1.693 in (17.9 cm x 12.4 cm x 4.3 cm) |
| Weight |
21.16 oz (600 g) |
