| CPU |
Broadcom BCM2711, Quad-core A72 (ARM v8) @ 1.5 GHz |
| Memory |
2GB LPDDR4 (1GB or 4GB or 8GB optional) |
| Flash Storage |
8GB eMMC (16GB or 32GB optional) |
| Ethernet |
1 x Gigabit Ethernet (Configurable as WAN or LAN) |
| Cellular |
4G LTE or 3G or 2G or NB-IoT / CAT-M1 |
| Wi-Fi |
Dual-band 2.4GHz or 5GHz, IEEE 802.11b or g or n |
| Antenna |
4G: SMA x 1 (internal), Wi-Fi or Bluetooth: SMA x 1 (internal) |
| SIM Slot |
1.8 V or 3 V, Nano SIM card drawer-type |
| Serial Ports |
RS-232 x 1, RS-485 x 1, with 15KV ESD protection |
| I/O Ports |
2 x Digital Input (DI), 2 x Digital or Pulse Output (DO) |
| USB Ports |
USB 2.0 x 2, USB-C x 1 (Power supply & Console) |
| HDMI |
HDMI 2.0 x 1, supporting up to 4K@60fps video output |
| Protection |
IP30 rated |
| Ambient Humidity |
5 to 95% (non-condensing) |
| Power Consumption |
10 W |
| Power Supply |
9 to 36 V DC or 1A |
| Operating Temperature |
-13°F to 158°F (-25 °C to 70 °C |
| Dimensions |
4.88 in x 2.99 in x 1.41 in (12.4 cm x 7.6 cm x 3.5 cm) |
