| Center Wavelength |
1310/1550 nm |
| Dynamic Range |
24/22 dB |
| Pulse Widths |
10 ns, 20 ns, 50 ns, 100 ns, 300 ns, 1.0 µs, 2.5 µs, 10 µs, 20 µs |
| Event Dead Zone |
(2 m) 6.56 ft |
| Attenuation Dead Zone |
(10 m) 32.8 ft |
| Distance Range |
0.5 km to 80 km (0.31mil to 49.7 mil) |
| Distance Measurement Accuracy |
±(1 m + Sampling Space + Measurement Distance × 0.005%) |
| Linearity |
±0.05 dB/dB |
| Visual Fault Locator (VFL) |
Center Wavelength: 650 nm ±20 nm; Output Power: <1 dBm; Fiber Type: SMF |
| Memory Capacity |
1000 Traces |
| Display |
3.5-inch LCD |
| Interface |
FC/UPC |
| Optical Connector |
FC/SC/ST (Universal Connector) |
| Battery |
NiMH Smart Charge Battery; Continuous Working Time: >10 Hours |
| Dimensions |
9.06 in x 4.72 in x 2.36 in (23 cm x 12 cm x 6 cm) |
| Weight |
1.98 lbs (0.9 kg) |
