| Performance Specifications |
| Frequency Range |
840 MHz to 960 MHz adjustable |
| Protocol |
EPC C1 GEN2 / ISO18000-6C |
| Frequency Band |
GB 920 MHz to 925 MHz840 MHz to 845 MHz FCC902 MHz to 928 MHz |
| Chip |
Impinj R 2000 |
| Read Range |
0 ft to 19.6 ft (0 m to 6 m) |
| Processor |
2.5 GHz or 2.3 GHz 8 core |
| RAM+ROM |
3 GB + 32 GB or 4 GB + 64 GB or 6 GB + 128 GB |
| Antenna Gain |
4 dBi |
| Communication |
wifi, bluetooth |
| Power |
| Power Supply |
12 V, 3 A |
| Power Consumption |
1 W |
| Operating Environment |
| Operating Temperature |
-4 °F to +122 °F (-20 ºC to +50 ºC) |
| Storage Temperature |
-40 °F to +158 °F (-40 ℃ to +70 ℃) |
| Working Humidity |
< 95 % 77 °F (+ 25 °C) |
| Physical Specifications |
| Dimension |
7.69 in x 6.09 in x 1.06 in(195.4 mm x 154.4 mm x 27 mm) |
| Net Weight |
23.07 oz (654 g) |
