| Type |
Embedded System Development Boards and Kits |
| Storage |
16 GB eMMC + TF(optional) + M.2 Nvme SSD(optional) |
| Network |
2x Giga LAN (RJ45) + WIFI + 5G or 4G(optional) |
| Power Supply |
DC 12V or 40W + LAN PD |
| Radiator |
Fin, without fan |
| OS |
Ubuntu 18.04(JP4.5 or JP4.6) |
| Fixed |
Table top placement or bracket installation |
| Warranty |
2 years |
| CPU |
6 core Camel ARM v8.2 64 bit CPU, 1.9 GHz |
| GPU |
Volta, 384 CUDA cores and 48 Tensor cores, 1.1 GHz, 21TFLOPS(INT8) |
| Encode |
2 x 464 MP per sec (HEVC), 2 K x 4 K at 30 (HEVC) 6 p x 1080 p at 60 (HEVC), 14 p x 1080p at 30 (HEVC) |
| Decode |
2 MP x 690 MP per sec (HEVC), 2 k x 4K at 60 (HEVC), 4K x 4K at 30 (HEVC) 12p x 1080p at 60 (HEVC), 32 p x 1080p at 30 (HEVC), 16 p x 1080p at 30 (H.264) |
| Memory |
16 GB 128 bit LPDDR4, Bandwidth 59.7 GB per S, 1600MHz |
| Extend |
2 x Mini PCIE(USB single and PCIe single, either PCIe or ssd can be selected ) |
| Display |
1 x HDMI2.0 (TypeA) |
| IO |
2 x USB 3.0, 1 x USB2.0, 1 x OTG, 1 x CAN, 1 x RS485, 1 x RS232, 8 x GPIOs |
| LED |
1 x Green LED(Power indication)， 2 x Green LED (Controlled by GPIO) |
| Button |
1 x Reset, 1 x Recovery |
| Material |
Aluminium |
| Color |
Black |
| MAX Power |
23 W |
| Dimensions |
7.8 in X 4.7 in X 38.0 in (200 mm X 120 mm X 965 mm ) |
| Weight |
52.9 oz (1500 g) |
