Description
Technical Specifications
| Processer | NVIDIA Jetson AGX Xavier 32 GB |
| AI Performance | 32 Tops |
| GPU | 512-core Volta GPU |
| CPU | 8-core ARM v8.2 64-bit CPU |
| Memory | 32 GB 256-Bit LPDDR4 |
| DL Accelerator | 2 × NV DLA Engines |
| Storage | 32 GB eMMC 5.1 |
| Video Encode | 4x 4Kp60
4x 4Kp60; 8x 4Kp30; 14x 1080p60; 16x 1080p60; 30x 1080p30; 32x 1080p30 (H.264) (H.265) |
| Video Decode | 2x 8Kp30; 4x 4Kp60; 6x 4Kp60; 8x 4Kp30; 12x 4Kp30; 16x 1080p60; 26x 1080p60; 32x 1080p30; 52x 1080p30 (H.264) (H.265) |
| Network/Camera | Ethernet
5×Gigabit Port Optional： 4 × PoE+ ，IEEE 802.3 af PoE 15.4W （max） |
| USB | USB
4 × USB 3.0 TYPE A 1 × USB 2.0 TYPE C USB 5V, 1A USB 2.0 Flashing Port |
| Operating Temperature | -4 °F to 140 °F (-20 ℃ to 60 ℃) |
| Storage Temperature | -13°F to 176°F (-25 ℃ to 80 ℃) |
| Storage Humidity | 10% to 90% non-condensing |
| Vibration | 3 Grms,10 Hz to 500 Hz, 1h/axis |
| Protection | IP5X |
| ESD | Touch 6 KV, Air 8 KV |
| Dimension | 8.90 in × 2.76 in × 5.69 in (226 mm × 70 mm × 144.5 mm) (I/O ports and mounting holes excluded) |
