Description
Technical Specifications
| Display Core | CPU integrated |
| CPU | Skylake-S, Kaby lake-S, Coffee Lake-S series |
| System Chipset | H310 |
| Memory Type | 1xSO-DIMMs DDR42400 |
| Memory Capacity | 16GB |
| JAE Terminal Output Interface | 1xHDMI1.4 (Max:3840x2160at 30Hz) 1xDP1.2 (Max:3840x2160at60Hz) optional |
| Front Output Interface | 1xDP1.2++ (Max:3840x2160at 60Hz) optional 1xHDMI1.4 (Max:3840x2160at 30Hz) |
| Internet | 1xRTL8111H gigabit network Support Wake-on-LAN and PXE boot |
| USB Interface | 3xUSB3.0 + 3x USB2.0 |
| Storage Interface | SATA=1x (6.35cm) 2.50-inch SATA HDD or SSD Mini PCIE=1xmSATASSD |
| Serial Interface | Support1xCOM-RS232protocolinterface (optional) |
| Extension Ports (M.2) | 1xM.22230, support WIF I or Bluetooth |
| Custom Function | Hardware automatic power-on function for incoming calls High reliability unattended system, one-key restore system |
| Software Functions | Watch Dog or Wake on LAN Windows10, Linux |
| Power | DC_IN12or19V |
| PG08 | Intel 6 or 7 or 8 or 9 CPU optional, H310Chipset 6x USB DP1.2+HDMI1.4+JAE, I219LM |
| Cooling Method | Direct blowing, double copper pipe side blowing optional, support temperature control and speed regulation |
| Materials | Metal |
| Operating Temperature | 32°Fto104°F (0°Cto40°C) |
| Storage Temperature | -4°Fto176°F (-20°Cto80°C) |
| Size | 7.09inx 7.68inx 1.65in (180mmx195mmx 42mm) |
