Description
Technical Specifications
| SoC | Rockchip RK3399Pro |
| CPU | Dual core ArmCortex A72 at 1.8 GHz |
| GPU | Arm MaliM T860 MP4 GPU at800 |
| OS Support | Debian 9 or Anroid 8.1 |
| Type | integrated circuit |
| Applications | Active |
| CPU | Dual to core ARM Cortex to A72 at 1.8 GHz Quad core ARM Cortex to A53 at 1.4 GHz |
| GPU | ARM MaliTMM to T860 MP4 GPU at 800 MHz |
| NN processor | |
| Display | 1 x HDMITM with CEC hardware ready
1 x USB Type to C (DP) 1 x 22 pin MIPI DSI (4 lane) |
| Memory Size | Dual to CH LPDDR4 3GB (SYSTEM) LPDDR3 1GB (NPU) |
| Storage | 16GB eMMC
Micro SD(TF) card slot (push or pull)
|
| Connectivity | 1 x RTL8211F to CG GbE LAN
1 x M.2 802.11 a or b or g or n or ac wireless & Bluetooth 5.0 (2T2R)
|
| Audio | 1 x 3.5mm audio jack (with Mic & plugin detection)
1 x S or PDIF TX pin 1 x PCM or 125 pins
|
| USB | 3 x USB 3.2 Gen1 Type A
1 x USB 3.2 Gen1 Type C OTG
|
| Camera Interface | 1 x 22 pin MIPI CSI 2 (4 lane)
1 x 22 pin MIPI CSI 2 or DSI (4 lane) |
