Description
Overview
Asset Track Pro’s Enterprise Network Switch with 24 Port Gigabit PoE is a 24-port Data Switch, with Network Essentials software. It switches extend the power of intent-based networking and hardware and software innovation to a broader set of deployments. With its family pedigree, it switches offer simplicity without compromise, it is secure, always on and IT simplified.
Technical Specifications
| Transmission Rate | 10 or 100 or 1000 Mbps |
| Communication Rate | Full Duplex & Half Duplex |
| Switch Capacity | 128 Gbps |
| Private Mold | No |
| Gigabit Ethernet Ports | 24 |
| Function | LACP, POE, QoS, SNMP, Stackable, VLAN Support |
| Condition | NIB Original |
| Warranty | 1 year |
| Description | 24x 10 or 100 or 1000 Ethernet PoE+ ports and 740W PoE budget, 4x 10G SFP+ uplinks |
| Uplink Interfaces | 4 SFP |
| POE + Power Budget | 370W |
| Fanless | N |
| CPU | ARM v7 800 MHz |
| DRAM | 512 MB |
| Flash Memory | 256 bits |
| Forwarding Bandwidth | 128 Gbps |
| Switching Bandwidth | 176 Gbps |
| Forwarding rate(64 byte L3 packets) | 95.23 Mpps |
| Dimension | 1.7 in X 17.5 in X 13.8 in (43.1 mm X 444.5 mm X 350.5 mm) |
| Weight | 12.1 lbs(5.5 kg) |
