Description
Technical Specifications
| Processor | 2 X 4th Gen Xeon Scalable or Xeon Max Processors |
| Memory | 32 x DDR5 RDIMM, Up to 4800 MT per s (1 DPC) or 4400 MT pr s (2 DPC) |
| Storage Controllers | PERC 11G: H755, H755N, H355, PERC 12G: H965i, H965e
HBA 11: HBA355i, HBA355e, BOSS-N1, Software RAID: S160 |
| Drive Bay | Front Bays:
(8.89 cm)3.5 inches, (6.35 cm) 2.5 inches – 24 Gb SAS, 6 Gb SATA, (6.35 cm)2.5 inches – Gen3 or 4 NVMe EDSFF E3.S – Gen5 NVMe |
| Power Supplies | AC (Platinum): 800 W, 1400 W, 2400 W
AC (Titanium): 700 W, 1100 W, 1800 W, 2800 W LVDC at -48 VDC Input: 1100 W |
| Form Factor | 2U rack server |
| Embedded Management | iDRAC9, iDRAC Direct, iDRAC RESTful with Redfish
iDRAC Service Manual, Quick Sync 2 Wireless Module |
| Open Manage Software | Cloud IQ for PowerEdge Plug in, Open Manage Enterprise
Open Manage Enterprise Integration for VMware vCenter Open Manage Integration for Microsoft System Center Open Manage Integration with Windows Admin Center, Open Manage Power Manager Plugin, Open Manage Service Plugin, Open Manage Update Manager Plugin |
| Bezel | Optional LCD Bezel or Security Bezel |
| Mobility | Open Manage Mobile |
| GPU | Supports Gpus, Including two Double-width Gpus or Six Single-width Gpus |
| Hard Disk | Optional 12x (8.89 cm) 3.5 – inch SAS3 or SATA; or 24x (6.35 cm) 2.5 – inch SAS4 or SATA, 24x NVME U.2 Gen4, 16x NVME E3.S Gen5. |
| Power Supply | 800W |
| Dimensions | Height: (86.8 mm) 3.41 in, Width: (482 mm) 18.97 in
Depth: (772.13 mm) 30.39 in with Bezel, (758.29 mm) 29.85 in without Bezel |
| Weight | 66.13 lb (30 Kg) |
