| Frequency |
865MHz to 865MHz(EU Standard), 902MHz to 928MHz (US standard) |
| Protocol |
ISO18000 to 6C(EPC GEN2) |
| Work Mode |
Answer Mode, Real to time to inventory, Trigger Mode |
| Type |
4 antenna UHF RFID reader |
| Chip |
High performance chip |
| Technical Support |
Yes |
| Application |
Warehouse Management |
| Max Inventory Speed |
200 Pcs per s |
| Reading Range |
3.2ft to 49.2 ft (1 m to 15 m) (depends on antenna gain) |
| Tag Buffer Size |
600 pcs at max. 128 bits EPC or 180 pcs at max.496 bits EPC |
| Inventory |
Support EPC and TID inventory |
| Antenna Port |
4 RP TNC Female |
| Device Connectivity |
RS232 OR RS485 OR USB OR RJ45 OR POE OR WIFI (optional) |
| General Purpose I or O |
2 optpcoupler input, 2 relay output |
| Support |
RSSI |
| RF Power |
33dbm (adjustable) |
| Power Supply |
12V |
| Current Dissipation |
0.5 to 1.2A |
| Working Humidity |
< 95 % RH 77 °F (+ 25 °C) Non-condensing |
| Operating Temperature |
14 °F to 140 °F (-10 ºC to +60℃) |
| Storage Temperature |
-4 °F to 167 °F (-20℃ to +75℃) |
| Reader Size |
7.2 in x 6.3 in × 1.0 in (184 mm x 161.7 mm x26 mm) |
| Net Weight |
21.1 oz (600 g) (0.6 kg) |
