| Shipping Term |
TNT, DHL, FEDEX, EMS, UPS |
| Condition |
Original Made Quality, Top Standard |
| Application |
Industry |
| Display |
Panel LED |
| Payment Term |
Advance |
| Protocol Support |
Standard/Special Protocol |
| Working Power |
Rated voltage: 9-48 VDC |
| Power Consumption |
<3 VA |
| Capacity Index (LAN) |
2 x 10/100M RJ45 interface |
| Serial Port |
2 x RS485 port + 1 x RS232 |
| Communication Master Station Protocols |
<16/pc |
| Transmission Mode |
Full or half duplex |
| Dual Machine Switching Time |
<5s |
| MTBF |
>50,000 hours |
| Status Indication |
Panel LED, reflecting the serial port data transmission and reception status |
| Standard Protocol |
IEC60870-5-101/103/104, MODBUS-TCP/IP, CDT, MQTT, etc. |
| Special Protocol |
DNP3.0 and other over 30 protocols, can be developed according to on-site needs |
| EMC |
Fast pulse group immunity, IEC61000-4-5, level 3, Surge immunity IEC61000-4-2, level 3, Electrostatic immunity IEC61000-4-4, level 3 |
| Working Environment |
Ambient temperature: -13 °F to 158 °F (-25 °C to +70 °C), Relative humidity: 5% ~ 95%, no condensation |
| Storage Temperature |
(-30 °C to +75 °C) -22 °F to 167 °F |
| Mounting Size |
DIN rail mounted |
| Size (L×W×H) |
1.65 in x 5.39 in x 4.33 in (4.2 cm x 13.7 cm x 11 cm) (KPM202) |
