| Power Supply |
AAA battery × 3 |
| Port |
RJ45, PoE |
| Tracking Type |
CAT6, CAT5 (STP & UTP) |
| PoE Test |
Check PoE switch standard (af/at) |
| Application |
Cable length measurement, Cable faults testing, PoE testing |
| Digital Cable Scanning |
Offers AC filter and analog signaling in one network toner and probe; features AC filter mode, analog mode, and PoE mode for cable tracking |
| Fault Distance Location |
Measures Cable length and locates fault distance accurately for LAN cables (range: 500m) |
| Multi-Function |
Includes cable length measurement, cable faults testing, PoE testing, hub blink, and NCV functions, ideal for cabling engineers |
| PoE Information Testing |
Identifies pins providing power, detects voltage levels, and PSE type (af/at standard). Locates network ports via flashing light on hub/switch |
| Cable Continuity Testing |
Tests physical status for STP and UTP LAN cables |
| NCV |
Detects AC voltage presence (50 V to 1000 V) |
