| Wavelength |
850nm, 1310nm, 1550nm |
| Tx Level |
-9 to -3dBm (850nm, 1310nm), 0 to -5dBm (1550nm) |
| Rx Sensitivity |
-20dBm (850nm), -22dBm (1310nm, 1550nm) |
| Transmission Distance |
550m (850nm), 10km (1310nm), 80km (1550nm) |
| Transmission Bit Rate |
1.25 Gbit/s |
| Rx Bit Rate |
1.25 Gbit/s |
| Working Wavelength Range |
830–860nm (850nm), 1270–1360nm (1310nm), 1540–1570nm (1550nm) |
| Frequency |
±4.6ppm |
| Optical Power |
±2dB |
| Jitter Compliance |
IEEE802.3 |
| Ethernet Type |
IEEE802.3 |
| Connecter |
LC |
| Transceiver |
SFP |
| TX Bit Rate |
10Mbit/s |
| RX Bit Rate |
10Mbit/s |
| TX Test Accuracy |
±4.6ppm |
| RX Test Accuracy |
±4.6ppm |
| Duplex Mode |
Full duplex |
| Jitter Compliance |
IEEEB802.3 |
| Connector |
RJ-45 |
| Line Rate and Code |
2.048 Mbps, HDB3 and AMI |
| Compliance |
ITU-T G.703 |
| Display |
5″800×480 color LCD touchscreen |
| Relative Humidity |
0% to 95%(non-condensing) |
| External Port |
USB,LAN Rj-45 |
| Working Time |
-7 hours[TC601+]:-5 hours [TC602]=3.5hours[TC602RE] |
| Charging Time |
5 hours from fully discharged to fully charged |
| Max Distance |
328.084ft (100m) |
| Dimension |
7.0 in x 5.7 in x 2.2 in (17.9cm x 14.5cm x 5.6 cm) |
| Working Temperature |
14 °F to 122 °F (-10°C to 50°C) |
| Storage Temperature |
−4∘F to (-20℃ to -70℃) |
| Weight |
1.8 lb (0.8 kg) |
