| Connector |
FC/UPC (Interchangeable SC, ST) |
| Network |
Wireless Lan, bluetooth, Wired LAN, ONVIF, TCP, Ip, POE, GPRS, wifi, 4g, GSM, 3G, wiegand, other |
| Type |
Testers &Tools, |
| File Format |
SOR Standard File Format |
| Loss Analysis |
4-point method / 5-point method |
| Laser Type |
FP-LD |
| Wavelength |
850 nm/980 nm/1300 nm/1310 nm/1490 nm/1550 nm/1625 nm/1650 nm |
| Output Power |
-50 dBm+26 dBm / -70 dBm+6 dBm |
| Mode |
CW/270 Hz/1 kHz/2 kHz |
| Stability |
CW, ±0.5 dB/15min (Test after 15 minutes of preheating) |
| Output Wavelength |
Consistent with OTDR output wavelength |
| Output Power (SM fiber) |
5 dBm |
| Loss Accuracy |
+0.03 dB/dB |
| Sample Points |
256 k |
| Sample Resolution |
0.049 ft to 3.28 ft (0.015 m to 16 m) |
| Reflection Accuracy |
12 dB |
| Loss Resolution |
0.001 dB |
| Loss Threshold |
0.01 dB |
| Laser Safety Level |
Class II |
| Refresh Rate |
4Hz (Typ.) |
| Data Storage |
Internal: 2 GB, 200,000 curves; External: 64 GB |
| Optical Connector: |
FC/UPC (Interchargeable SC,ST) |
| Operating Temperature(℃) |
14 ℉ to 122 ℉ (-10 to +50 ℃) |
| Storage Temperature (℃) |
-40 ℉ to 158 ℉ (-40 to +70 ℃) |
| Dimension(mm) |
8.46 in x 6.29 in x 1.96 in (21.5 cm x 16 cm x 5 cm) |
