Description
Technical Specifications
| CPU | 10th Gen. i3 i5 i7 |
| COM | 3 x RS232, DB9, 2 x RS485 Optional |
| Memory | 1 x DDR4 2133Mhz SO-DIMM Sockets, up to 16GB |
| Storage | M.2 SSD |
| I/O Ports | 4 x USB3.0 + 2xUSB2.0, Type-A |
| OS | Windows or Linux |
| Display Port | VGA + HD-MI |
| Luminance | 300nits |
| Cooling System | Fanless |
| Network(LAN) | 2 x I211 10 or 100 or 1000Mbps Ethernet |
| Power Supply | 12V DC (3 Pin Phoenix Connector) , Optional 9V-36V DC; 1x Power SW, AT or ATX Optional |
| Color | Black |
| Material | High Strength Aluminum Alloy Front Panel |
| Operating Temperature | 32°F to 122°F (0°C to 50°C) (extend temperature optional) |
| Storage Temperature | -4°F to 158°F (-20°C to 70°C) (extend temperature optional) |
| Dimensions | 7.67 x 6.22 x 1.68 in (195 x 158 x 42.8mm) |
| Weight | 3.74 lbs (1.7 KG) |
