| CPU Options |
Intel Core i3-4030U (Dual Core, 1.90 GHz), i5-4200U (Dual Core, 1.60 GHz), i7-4500U (Dual Core, 1.80 GHz) |
| RAM |
2× DDR3 SO-DIMM slots, supports 4 GB / 8 GB / 16 GB |
| Storage |
1× mSATA SSD (supports 128 GB / 256 GB / 512 GB / 1 TB), 1× SATA 2.5″ HDD/SSD interface |
| Graphics |
Integrated Intel HD Graphics |
| Display Ports |
HDMI + VGA display output |
| I/O Ports |
8× USB, 2× LAN, HDMI + VGA, 6× COM (4× RS232/485), 1× GPIO, 1× PS/2, 1× SIM slot, 1× Audio jack, 2× Wi-Fi antenna ports, Power switch and input |
| Network |
Dual RTL8111G/H Gigabit Ethernet, supports 2.4G/5G Wi-Fi and 4G SIM module |
| Audio |
Integrated Realtek sound card |
| Supported OS |
Windows 7/8/10/11, Linux, CentOS, Pfsense |
| Operating Temperature |
-10°C to 60°C (14°F to 140°F) |
| Relative Humidity |
10%–90% (non-condensing) |
| Power Consumption |
CPU: 15 W, Total System: 25 W |
| Cooling System |
Fanless passive cooling |
| Dimensions (W×D×H) |
220 mm × 155 mm × 55 mm (8.66 in × 6.10 in × 2.17 in) |
| Material |
Aluminum alloy enclosure |
| Plug Types |
US / AU / UK / EU (customizable) |
| BIOS Features |
Auto power-on, network wake-up, diskless boot |
| Installation |
Desktop, wall-mount, or embedded |
| Color Options |
White and black (customizable for bulk orders) |
| Power Supply |
External adapter, Input AC 100–240 V, Output DC 12 V |
