| Wavelength |
1310 nm/1550 nm ±20 nm |
| MOQ |
1 Piece |
| Function |
9 in 1 |
| Loss Accuracy |
±0.05dB/dB |
| Dynamic Range |
24/22dB |
| Measuring Pulse Width |
3ns to 10us |
| Ranging Accuracy |
± (1m + Sampling interval + 0.005% x Test distance) |
| Loss Precision |
±0.05dB/dB |
| Sampling Number |
16k to 256k |
| Relative Humidity |
0 to 95% |
| Reflection Accuracy |
±3dB |
| Data Storage |
≥600; Can add TF card |
| Laser Safety Level |
Class 2 |
| File Format |
SOR |
| Interface Type |
FC/PC (Replaceable SC, ST) |
| Power Meter Pass Zone (nm) |
800nm to 1700nm |
| Connector |
Universal FC/SC/ST |
| Measurement Range (dBm) |
-50dBm to +26dBm |
| Connatural Uncertainty (dB) |
±5% |
| Frequency Identification |
CW/270/330/1k/2kHz |
| Calibration Wavelength |
850/980/1300/1310/1490/1550/1625/1650nm |
| Light Source |
Laser FP-LD |
| Output Wavelength (nm) |
1310nm/1550nm ±20nm |
| Output Power (dBm) |
≥-5dBm |
| Modulation Frequency |
270/330/1k/2kHz |
| Stability |
CW, ±0.5dB/15min (Test after Power on 15min) |
| VFL Wavelength |
650nm ±20nm |
| VFL Power |
≥2mW |
| VFL Working Model |
CW/1Hz/2Hz |
| Network Cable Test Function |
Test RJ45 Connector working or not after installation |
| Lighting Function |
Yes |
| Data Interface |
Micro USB |
| External Storage |
TF Card |
| Power |
Lithium polymer battery: 3.7V, 4000mAh; Power adapter: 5VDC, 2A |
| Battery Life |
Standby > 7.5 hours; Testing > 4 hours |
| Test Range |
1640.42 feet (500 m) to 37.28 miles (60 km) |
| Event Dead Zone |
9.84 feet (3 m) |
| Attenuation Dead Zone |
26.25 feet (8 m) |
| Lan Tester Distance |
984.25 feet (300 m) |
| Accuracy of Measurement |
±2m |
| OTDR Display |
3.5 inch color LCD display |
| Weight |
0.79 lb(0.360kg) (Without Packing); 1.68 lb(0.760kg )(With Packing) |
| Dimension |
6.81 in x 3.23 in x 1.46 in(17.3 cm x 8.2 cm x 3.7 cm) |
| Sampling Resolution |
0.164 feet to 26.25 feet (0.05 m to 8 m) |
| Working Temperature |
14 °F to 122 °F (-10 ℃ to 50 ℃) |
| Storage Temperature |
-4 °F to 158 °F (-20 ℃ to 70 ℃) |
