| Wavelength |
1550 nm (optional) |
| Output Power |
≥ -5 dBm |
| Spectral Width (FWHM) |
≤ 5 nm |
| Frequency |
CW, 270, 1K, 2KHz |
| Power Stability |
≤ ±0.1 |
| Detector Type |
Ingas |
| Port |
MPO Male connector |
| Measuring Range |
+3 dBm to -50 dBm |
| Power Measurement Linearity |
±0.1 dB |
| Power Measurement Uncertainty |
±0.25 dB |
| OLS Wavelength |
1550 nm (optional) |
| OLS Output Power |
≥ -5 dBm |
| OLS Spectral Width (FWHM) |
≤ 5 nm |
| OLS Frequency |
CW, 270, 1K, 2KHz |
| OLS Power Stability |
≤ ±0.1 |
| OPM Detector Type |
Ingas |
| OPM Wavelength |
850 nm, 1300 nm, 1310 nm, 1550 nm |
| OPM Measuring Range |
+3 dBm to -50 dBm |
| OPM Power Measurement Linearity |
±0.1 dB |
| OPM Power Measurement Uncertainty |
±0.25 dB |
| OPM Port |
MPO Male connector |
| OPM Resolution Ratio |
0.01 dB |
| OPM Polarity Detection |
A, B, C & user-defined |
| OPM Record Storage |
Applied |
| Wavelength Test Range |
800 nm to 1700 nm |
| Wavelength (Other) |
850/1300/1310/1490/1550/1625 nm |
| Measuring Range (Other) |
+26 dBm to -50 dBm |
| Uncertainty (Other) |
≤ 0.25 dB |
| VFL Wavelength |
650 nm |
| VFL Output Power |
10 mW |
| Display Size |
5.6 in (14.22 cm) TFT color screen |
| Power Supply |
7.4V 4000mAh Lithium battery/Micro USB |
| Automatic Shutdown Time |
User-defined optional |
| Low Battery Warning |
Icon flashing |
| Communication Interface |
Micro USB |
| Standard Configuration |
1. Main device (1) |
| Operating Temperature |
14 °F to 140 °F (-10 °C to +60 °C) |
| Storage Temperature |
-13 °F to 158°F (-25 °C to +70 °C) |
| Dimensions |
10.24 in x 6.1 in x 2.87 in (26 cm x 15.5 cm x 7.3 cm) |
| Weight |
44.68 oz (1250 g) |
