| Use |
FTTx |
| Warranty Time |
1 year |
| Fiber |
SMF |
| Wavelength |
1310 nm/1550 nm |
| Dynamic Range |
32/30dB |
| Display Screen Type |
7-inch TFT-LCD touch screen |
| Connector |
FC, SC, LC/UPC |
| Data Storage |
SD Card (4G), >10,000 pieces |
| Interface |
3 USB ports (USB 2.0, Type A USB2, Type B USB1) |
| Power Supply |
AC/DC adapter: 100 V to 240V, 50/60Hz; Internal Li Battery: 11.1V, 6800mAh |
| Built-in Power Meter |
-70 dBm to +10 dBm |
| Built-in Visual Fault Locator |
650 nm / 10 mW |
| Environmental Adaptability |
RH: 5 % to 95 %, no condensation |
| Operating Temperature |
14 °F to 122 °F (-10 °C to +50 °C) |
| Storage Temperature |
-40 °F to 158 °F (-40 °C to +70 °C) |
| Weight |
Approximately 3.97 lb (1.8 kg) |
