| Optical Interface |
FC/UPC (PC and APC selectable) |
| Data Interface |
USB, SD card |
| Visible Fault Locator |
650 nm wavelength, ≥-3 dBm output power, max testing distance 1.86 miles (3 km) |
| Power Supply |
Lithium battery continuous operation ≥8 hours |
| Wavelengths |
850/1300 nm (multimode), 1310/1550 nm (single-mode) |
| Dynamic Range |
23 to 21 dB (multimode), 32 to 30 dB (single-mode) |
| Pulse Widths |
5 to 20,480 ns |
| Event Dead Zone |
6.6 ft (2 m) |
| Attenuation Dead Zone |
29.5 ft (9 m) |
| Linearity |
±0.05 dB/dB |
| Loss Threshold |
0.05 dB |
| Loss Resolution |
0.01 dB |
| Sampling Resolution |
0.41 ft to 26.25 ft (0.125 to 8 m) |
| Sampling Points |
32,000 |
| Distance Uncertainty |
±(3.28 ft + 5×10⁻⁵× distance + sampling interval) [±(1 m + 5×10⁻⁵× distance + sampling interval)] |
| Distance Range |
0.19 to 111.85 miles (0.3 to 180 km) |
| Real-Time Refresh Rate |
0.2 seconds |
| Trace Memory Capacity |
SD Card (2 GB), >10,000 traces |
| Operating Temperature |
14°F to 122°F (-10°C to 50°C) |
| Dimensions (H×W×D) |
5.91 in ×9.25 in ×2.6 in (15 cm × 23.5 cm ×6.6 cm) |
| Weight |
3.3 lbs (1.5 kg) |
