| Optical Port Type |
FC/PC (interchangeable SC, ST) |
| Data Interface |
USB, mini-USB, 10M/100M Ethernet port |
| Loss Accuracy |
2.46 ft (0.75 m) + sampling interval + 0.005% × test distance) |
| Reflection Accuracy |
±0.05 dB/dB |
| Data Storage |
≥2000 |
| VFL Output |
>5 mW |
| Light Source Output |
>-5 dBm |
| Optical Power Meter |
+26 dBm to -50 dBm (Replaceable: +6 dBm to -70 dBm) |
| Power Supply Mode |
AC/DC adapter: AC: 100 V to 240 V, 50/60 Hz, 0.6 A; Lithium battery: 7.4 V, 6700 mAh, Li-ion |
| Operating Temperature |
23 ℉ to 122 ℉ (-5 °C to 50 °C) |
| Storage Temperature |
-4 ℉ to 158 ℉ (-20 °C to 70 °C) |
| Relative Humidity |
0 % to 95% non-condensing |
| Volume |
8.93 in x 6.29 in x 2.75 in (22.7 cm x 16 cm x 7 cm) |
| Machine Weight |
24.25 lb (11 kg) |
