| Type |
Finished Batteries Tester |
| Application |
Lithium-ion Battery |
| Material |
Metal |
| Input Power |
AC 380V ±10%, 50/60 ±5Hz |
| Power Factor |
≥99% (full load) |
| Charge/Discharge Current Distortion Rate |
≤5% (full load) |
| Input Impedance |
≥1 MΩ |
| Input Power |
31.3 kW |
| Machine Efficiency |
≥90% (full load) |
| Noise Level |
≤80 dB |
| Number of Channels |
2 |
| Single Channel Power |
14.4 kW |
| Overall Output Power |
28.8 kW |
| Range |
Charge 0V to 120V, Discharge 6V to 120V |
| Precision |
≤0.05% FS |
| Resolution |
1 mV |
| Current Response Time |
10 ms (10% FS to 90% FS) |
| Charge-Discharge Conversion Time |
20 ms (-90% FS to 90% FS) |
| Operating Humidity Range |
≤70% RH (no condensation) |
| Storage Humidity Range |
≤95% RH (no condensation) |
| Operating Temperature Range |
0°C to 45°C (32°F to 113°F) |
| Storage Temperature Range |
-10°C to 50°C (14°F to 122°F) |
| Device Dimensions |
27 in x 28.7 in x 57.9 in (68.6 cm x 73 cm x 147 cm) |
| Weight |
550 lb (≤250 kg) |
