| Item |
OTDR |
| Optical Fiber Type |
Single-mode |
| Central Wavelengths |
1310/1550nm |
| Maximum Dynamic Range |
32/30dB |
| Optical Interface |
FC/PC (Replaceable SC, ST) |
| Ranging Accuracy |
± (2.5 ft (0.75m) + Sampling interval + 0.005% × Test distance) |
| Attenuation Measurement |
±0.05 dB/dB |
| Reflection Measurement |
±3dB |
| Data Storage |
≥2000 |
| Communication Interface |
USB, mini-USB, 10M/100M Ethernet |
| VFL Output Power |
≥5mW |
| LS Output |
≥-5dBm |
| OPM |
+26dBm to -50dBm (+6dBm to -70dBm Replaceable) |
| Power Supply Mode |
AC/DC Adapter: AC: 100 to 240V, 50/60Hz, 0.6A; Lithium battery: 7.4V 6700mAh |
| Event Dead Zone |
3.3 ft (1m) |
| Attenuation Dead Zone |
19.7 ft (6m) |
| Relative Humidity |
0 to 95% Non condensation |
| Operating Temperature |
23 °F to 122 °F (-5 °C to 50 °C) |
| Storage Temperature |
-4 °F to 158 °F (-20 °C to 70 °C) |
| Dimension |
8.9 in x 6.3 in x 2.8 in (22.7 cm x 16 cm x 7 cm) |
| Weight |
2.4 lbs (1.1kg) |
