| IOLA |
Multipulse test using a mix of short, medium, and long pulses |
| Display |
7-inch color LCD, Multi-touch screen |
| Connector |
FC/PC (1310/1550 nm) interchangeable adapter or customize |
| Measurement Mode |
Real time, Average, Automatic |
| Test Range |
0.06 mi to 49.71 mi (0.1 km to 80 km) |
| Wavelength |
1550 (± 20 nm) x ZS1000-A/B both support 1310 (± 20 nm) x Support ZS1000-A only |
| Measurement Time |
5 s to180 s |
| Pulse Width |
5 ns to 20 μs |
| Attenuation Dead Zone |
39.37 ft (12 m) |
| Event Dead Zone |
3.28 ft (1 m) |
| Min. Distance Resolution |
0.32 ft (0.1 m) |
| Loss Resolution (dB) |
0.001 dB |
| Distance Uncertainty (m) |
± (0.8 + 0.005% x Testing Distance + Resolution) |
| OPM Function |
+26 to -50 dBm, 850/980/1270/1300/1310/1490/1550/1577/1625/1650 nm, FC or SC adapter |
| VFL Function |
10 mW |
| Storage |
>10,000 results (SOR or PDF) |
| Battery |
7.4 V/4.6 AH Rechargeable lithium-ion batteries |
| Storage Temperature |
-4 ℉ to 140 ℉ (-20 °C to + 60 °C), < 90%RH |
| Operating Temperature |
14 ℉ to 122 ℉ (-10 °C to +50 °C), < 90%RH |
| Size (HWD) |
9.70 in x 6.830 in x 2.75 in (24.65 cm x 17.35 cm x 7 cm) |
| Weight |
About 3.41 lb (1.55 kg) |
