Description
Features
- Multi-GNSS Support
- Industrial-Grade Design
- High Sensitivity and Accuracy
- Fast Acquisition Time
- RS232 Data Interface
Technical Specifications
| Frequency | GPS L1, GLONASS L1, BDS B1, GALILEO E1, SBAS L1, QZSS L1 |
| Data Level | RS-232 level |
| NMEA Message | RMC, VTG, GGA, GSA, GSV, GLL |
| VCC | DC Voltage 3.6 V to 5.5 V, Typical: 5.0 V |
| Tracking Sensitivity | -162 dBm |
| Reacquisition Sensitivity | -160 dBm |
| Support Rate | 4800 bps to 921600 bps, Default 9600 bps |
| Acquisition Time | 26 s to 25 s |
| Operating Temperature | -40°F to 185°F (-40°C to 85°C) |
| Dimension | 6.3 in x 6.3 in x 6.3 in (16 cm x 16 cm x 16 cm) |
| Weight | 52.91 oz (< 1500 g) |
