Description
Features
- Real-time tracking via Web and App
- Geo-fencing
- History report and playback
- Fuel consumption/leak/addition report (Supports up to 5 RS232 connection sensors)
- Temperature monitoring (Supports up to 4-channel temperature sensors)
- Weight sensor (0 to 100T, above 100T requires customization)
- Location report
- Mileage overview and mileage monthly report
- Parking report
- Ignition status report
- Rotation sensor report
- Device online/offline report (Daily and Monthly)
- Engine idle report
- Sub-user management
- Insurance records management
Technical Specifications
| Internet | 2G GSM 850, 900, 1800, 1900 MHz, 4G TD-LTE: B34, B38, B39, B40, B41, FDD-LTE: B1, B2, B3, B4. B5, B6, B8, B18, B19, B26, WCDMA: B1, B2, B4, B5, B6, B8, B19 |
| Communication Protocol | TCP/IP |
| GNSS Details | GPS, BeiDou, GLONASS |
| Positioning Accuracy | 32.08 ft (10 m) |
| Speed Accuracy | 0.33 ft per s (0.1 m per s) |
| Capturing Sensitivity | -148 dBm |
| Tracking Sensitivity | -165 dBm |
| Cool Start | < 32 s |
| Hot Start | < 2 s |
| GNSS Antenna | 25 mm × 25 mm × 2 mm, Built-in |
| Memory | 32 MB + 32 MB + 128 KB |
| Switch | On, Off |
| SIM Card | Micro-SIM |
| Signal Light | Blue for GPS, Green for GSM, Red for Power |
| Battery | 200 mAh 3.7 V Li-Polymer Industry Battery |
| Working Voltage | 9 V to 45 V, DC (24 mA at 12 V DC, 12 mA at 24 V DC) |
| Interface | 5 V Output for Alarm Speaker Control, Supports RS232 or RS485, Supports Engine Immobilization |
| AGPS | Support |
| Operating Temperature | -4 °F to 158 °F (-20 °C to 70 °C) |
| Dimensions | 3.78 in × 1.69 in × 0.79 in (9.6 cm × 4.3 cm × 2.0 cm) |
| Weight | 3.88 oz (110 g) |
