| Wavelength |
1310 nm ±20 nm / 1550 nm ±20 nm |
| Dynamic Range |
32/30 dB |
| Event Blind Zone |
4.9 ft (1.5 m) |
| ATT Blind Zone |
26.2 ft (8 m) |
| Test Range |
1640 ft to 79 mi (500 m to 128 km) |
| Pulse Width |
5 ns to 10000 ns |
| Ranging Accuracy |
± (3.28 ft + Sample interval + 0.005% × Test distance) |
| Loss Accuracy |
±0.05 dB/dB |
| Sampling Points |
16 k to 128 k |
| Sampling Resolution |
0.16 ft to 52.5 ft (0.05 m to 16 m) |
| Reflection Accuracy |
±4dB |
| File Format |
SOR Standard file format |
| Loss Analysis |
4-point method / 5-point method |
| Data Storage |
Internal ≤1000 curves; External: 4GB |
| Connector |
FC / UPC (Interchangeable SC, ST) |
| Laser Safety Level |
Class II |
| Refresh Rate |
3Hz (Typ.) |
| Data Interface |
USB |
| Display |
3.5-in Color LCD + Touch Screen |
| Power Supply |
AC / DC Adapter: Input 100V to 240V, 50 / 60Hz, 0.6A; Output: 12V to 19V, 1.5A, Li-Battery: 7.4V, 5200mAh |
| Battery Working Hours |
≥10 h |
| Operating Temperature |
14 °F to 122 °F (-10 °C to +50 °C) |
| Storage Temperature |
-40 °F to 158 °F (-40 °C to +70 °C) |
| Relative Humidity |
0% to 95% non-condensing |
| Dimension |
8.19 in × 4.33 in × 2.2 in (20.8 cm × 11 cm × 5.6 cm) |
| Weight |
< 35.27 oz (<1 kg) |
