| Display |
5.6” LCD touch screen |
| Memory Capacity of Trace |
SD Card (4G) ≥1000 pcs |
| Duration of Measurement |
Defined by user: 5s, 10s, 15s, 30s, or 1min, 2min, 3min |
| Dynamic Range (dB) |
21/19, 32/30, 32/30/30, 34/34 36/35 |
| Wavelength (nm) |
850 to 1300, 1310 to 1550, 1310 to 1490 to 1550, 1625 |
| Push Width (ns) |
5 to 20480 |
| Event Blind Zone (ft) |
32.8 ft (10 m), ≤5.91ft (≤1.8 m) |
| Attenuation Blind Zone (ft) |
65.62 ft (20 m), ≤32.81ft (≤10 m) |
| Linearity (dB) |
±0.05 |
| Loss Threshold (dB) |
0.05 |
| Loss Resolution Ratio (dB) |
0.01 |
| Sampling Resolution Ratio (ft) |
0.41ft to 26.25ft (0.125m to 8m) |
| Sampling Point |
32 K |
| Distance Uncertainty (ft) |
± (3.28ft + 16.4ft × distance + sampling interval) |
| Distance Scope (mi) |
0.19 mi (0.3 km) to 111.85 mi (180 km) |
| Typical Real-Time Refreshing |
0.2 |
| Dimension |
5.91 in × 9.25 in × 2.60 in (15 cm × 23.5 cm × 6.6 cm) |
| Weight |
3.3 lbs (1.5 kg) |
