Description
Features
- Quick startup
- Built-in PON meter
- High configuration modules
- Dustproof and shockproof
Technical Specifications
| Data Storage | 1000 records |
| Connectivity | USB |
| Optical Port | FC/SC/ST interchangeable port |
| Power Supply | NiMH Rechargeable Battery/AC adapter |
| Battery Life | 8 hrs continuous operation, 20 hrs standby (on one charge) |
| Pulse Width | 10 to 10,000 ns |
| Testing Range | 328 ft to 149 miles (0.1 to 240 km) |
| Testing Time | 15 to 180 seconds |
| Linearity (dB) | ±0.05 |
| Reflection Detect Accuracy | ±4 dB |
| Relative Humidity | 0 to 95% (non-condensing) |
| Operating Temperature | -4°F to 122°F (-20°C to 50°C) |
| Storage Temperature | -40°F to 158°F (-40°C to 70°C) |
| Dimensions | 8.66 in × 4.33 in × 2.76 in (22 cm × 11 cm × 7 cm) |
| Weight | 2.2 lbs (1 kg) |
