Description
Features
- Communication: GPRS, ZigBee, LoRa, LoRaWAN, NB-IoT
- Load bearing: ≥5 tons
- Frequency: 433/470/868/915/923, B1/B3/B5/B8/B20
- Working Temperature: -20℃ to +70℃
- Shell Material: PC+ABS
- Transmission Distance: 500m to 5km
- Battery Life: 3 to 5 years (replaceable)
- Protection Level: IP68
- Configuring Serial Port: 9600, n,8,1
- Antenna Interface: Built-in FPC antenna
- Maximum Working Current: <300mA
Technical Specifications
| Type | Carport |
| Warranty | 12 Months |
| Accuracy | 95 % |
| Communication | GPRS, ZigBee, LoRa, LoRaWAN, NB-IoT |
| Load Bearing | ≥5tons |
| Frequency | 433/470/868/915/923, B1/B3/B5/B8/B20 |
| Working Temperature | -4 °F a 158 °F (-20 ℃ to + 70 ℃) |
| Shell Material | PC+ABS |
| Transmission Distance | 500 m to 5km |
| Battery Life | 3 to 5 years (replaceable) |
| Protection Level | IP68 |
| Voltage | 3.6 V |
| Configuring Serial Port | 9600, n,8,1 |
| Antenna Interface | Built-in FPC antenna |
| Maximum Working Current | <300 mA |
| Weight | 11.52 lbs (5.230 kg) |
| Size | 16.54 in x 16.54 in x 10.24 in. (42 cm x 42 cm x 26 cm) |
