Description
Features
- Ultra-High Capacity: High-Density 400GE/100GE/40GE Aggregation
- Large Buffer: Adequately Coping with Traffic Bursts
- Network-Wide High Reliability and High Service Continuity During Network Faults
- Programmable Network Devices for Flexible Customization
- Intelligent Lossless Network, Meeting High Performance Requirements of RoCEv2 Applications
- Intelligent O&M Through Interworking with iMaster NCE-FabricInsight
- Zero Touch Provisioning (ZTP), Implementing Automatic O&M
- Flexible Airflow Design, Improving Energy Efficiency
- Clear Indicators, Simplifying O&M
Technical Specifications
| Device Type | Switch |
| Transmission Rate | 40/100/400 Gbps |
| Ports | 4 subcard slots, up to 32 × 400GE QSFP-DD or 128 × 100GE QSFP28 |
| Functionality | LACP, QoS, SNMP, Stackable, VLAN support |
| Communication Mode | Full-Duplex |
| Chassis Height | 4U |
| Switch Capacity | 25.6 Tbps |
| Forwarding Performance | 8000 Mpps |
| Maximum Power Consumption | 1.231 kW |
| Weight | 101.94 lb (46.2 kg) |
| Dimensions (W × D × H) | 17.40 in × 30.12 in × 6.89 in (442 mm × 765 mm × 175 mm) |
