| Testing Modes |
Automatic and Manual |
| Wavelengths Supported |
Multiple, including 1310 nm, 1550 nm, 1625 nm, and 1650 nm |
| Visible Laser Source |
Integrated for visual fault location |
| In-Line Testing |
Supports through splitter testing at 1625 nm and 1650 nm with filter |
| OTDR Module |
Supports up to four wavelengths; Single-Mode (SM) and Multi-Mode (MM) options available |
| Fault Detection |
Identifies faults, measures fiber length, loss, return loss, and detects connectors, splices, splitters, macro bends, and fiber ends |
| Applications |
Suitable for LAN, WAN, and FTTx deployments |
| File Formats |
Supports GR-196-CORE (.SOR) and JPG formats; flexible file naming |
| Display |
7-inch touch screen |
| Dynamic Range |
Up to 50 dB |
| Event Dead Zone (EDZ) |
2.6 feet (0.8 m) |
| Attenuation Dead Zone (ADZ) |
13.1 feet (4 m) |
| Dimensions |
11.4 in x 6.9 in x 3 in (29 cm x 17.5 cm x 7.5 cm) |
| Operating Temperature |
-4 °F to 122 °F (-20 °C to 50 °C) |
| Weight |
3.3 lbs (1.5 kg) |
