| Module |
NVIDIA Jetson AGX Orin 64GB |
| AI Performance |
275 TOPS |
| Memory |
64 GB 256-bit LPDDR5, 204.8 GB/s |
| On Board Storage |
64 GB eMMC 5.1 |
| CSI Camera |
Up to 6 cameras (16 via virtual channels), 16 lanes D-PHY 2.1 (up to 40 Gbps) / C-PHY 2.1 (up to 164 Gbps) |
| Video Encode |
1 × 4K60 | 3 × 4K30 | 6 × 1080p60 | 12 × 1080p30 (H.265), H.264, AV1 |
| Video Decode |
1 × 8K30 | 3 × 4K60 | 4 × 4K30 | 9 × 1080p60 | 18 × 1080p30 (H.265), H.264, VP9, AV1 |
| Ethernet |
6 × 10/100 MbE, RJ45 |
| Display |
1 × HDMI 2.0 |
| Audio |
Mic-in (Mono), Line-out (Stereo) |
| USB |
2 × USB 3.0 (Type-A), 2 × USB 2.0 (Type-A) |
| COM Ports |
1 × RS485, 1 × RS232, 1 × CAN FD |
| Expansion IO |
2 × RS232, 2 × RS485, 2 × CAN, 2 × GPIO Input, 2 × GPIO Output |
| Wireless Connectivity |
2 × Antennas for 4G/Wi-Fi (SMA), 1 × SIM Slot (4G module support) |
| System Storage Options |
1 × M.2 SSD Slot (2280, NVMe interface), 1 × Micro SD Slot |
| Power Input |
DC 9 – 36 V, supports ACC |
| IP Rating |
IP65 |
| Cooling |
Fanless passive cooling |
| Operating Temperature |
−4 °F to 140 °F (−20 °C to +60 °C) |
| Storage Temperature |
−40 °F to 185 °F (−40 °C to +85 °C) |
| Operating Humidity |
10 % – 95 % RH, Non-condensing |
| Storage Humidity |
10 % – 95 % RH, Non-condensing |
| Dimension |
10.16 in × 7.12 in × 3.74 in (258 mm × 180.9 mm × 95 mm) |
| Weight |
9.92 lb (4.5 kg) |
