| Shape / Height |
2U Rack Server |
| Processor |
Up to 2 × 3rd Gen Intel® Xeon® Scalable Platinum Series, up to 40 cores, up to 270W TDP |
| Memory |
32 DDR4 Memory Sockets; Supports up to 32 × 128GB 3DS RDIMMs; Up to 16 Intel® Optane™ Persistent Memory 200 Series Modules |
| Drive Bay |
Up to 20 × 3.5″ or 40 × 2.5″ drives; Up to 32 NVMe drives with NVMe switch adapter; 2 × M.2 boot drives (RAID 1); Back-end 2 × 7mm boot drives (RAID 1) |
| Expansion Slots |
Supports up to 10 PCIe slots, including 8 PCIe 4.0 slots, 1 OCP 3.0 slot, and 1 HBA/RAID adapter slot with cable |
| Network Interface |
LOM adapter installed in OCP 3.0 slot; Multiple PCIe adapters supported simultaneously |
| Power Supply |
Dual Redundant Power Supply (maximum 1800W Platinum) |
| System Management |
Lenovo XClarity Controller |
| GPU Support |
Up to 8 single-width or 3 double-width GPUs |
| USB Ports |
Front: 1 × USB 3.1 Gen 1, 1 × USB 2.0 (supports XClarity Mobile), 1 × VGA (optional), 1 × External diagnostic phone port Back: 3 × USB 3.1 Gen 1, 1 × VGA, 1 × RJ-45 (Management), 1 × Serial port (optional) |
| HBA / RAID Support |
Standard software RAID; Optional hardware RAID with/without cache or 8/16-port SAS HBA |
| Embedded Management-1 |
IPMI 2.0 compliant |
| Embedded Management-2 |
iDRAC9 with Lifecycle Controller (Express, Enterprise) |
| Embedded Management-3 |
Quick Sync 2 wireless module optional |
