Description
Technical Specifications
| Processor | 10th 11th Core i3 i5 i7 processor |
| Graphics Card | Core graphics card, Intel HD Graphics |
| Display Port | HD+VGA display |
| RAM | 2 X DDR3 SO-DIMM, Support 4G or 8G or 16G |
| Storage | 1 x MSATA SSD interface, Support 128G or 256G or 512G or 1TB, etc 1 x SATA (6.35 cm)2.5-inch HDD/SSD interface |
| I/O | 8x USB, 2 x Network interface, HD+VGA Display Interface, 6 x COM (4 x RS232 or 485), 1 x GPIO, 1 x PS or 2, 1 x SIM card slot, 1 x Audio Interface, 2 x Wi-Fi antenna interface, 1 x Power switch, 1 x power interface |
| Network | 2 x RTL8111G or H gigabit network card, Support 2.4G or 5G WIFI communication, A SIM card holder, Support 4G module |
| Audio | Realtek sound card |
| Supported OS | Windows7 or 8 or 10 or 11 or Linux or Centos or Pfsense |
| Power Consumption | CPU: 15W, Total PC: 25W |
| Cooling System | No Fan passive Cooling |
| Material | High-quality all aluminum alloy case |
| Installation | Desktop type or Wall type or Embedded |
| BIOS | Support auto power-on or network wake-up or diskless start-up |
| Power Supply | External power adapter, Input AC 100V to 240V, Output DC 12V |
| Relative Humidity | 10% to 95% RH, non-condensing |
| Operating Temperature | 14°F to 140°F (-10°C to 60°C) |
| Dimension | 9.25 x 6.10 x 1.97 in (235 x 155 x 50 mm) |
