| Frequency |
865 MHz to 868 MHz or 902 MHz to 928 MHz |
| Protocol |
ISO18000-6C(EPC C1G2), ISO18000-6B |
| Interface |
RS232, RS485, RJ45(TCPIP), USB with WiFi and POE optional |
| Reading Range |
3.2 ft to 49.2 ft (1 m to 15 m) (depends on antenna gain) |
| Chip |
Impinj E710 Chip |
| Max Inventory Speed |
800 pcs per sec |
| Tag Buffer Size |
600 pcs max 128 bits EPC or 180 pcs max 496 bits |
| Antenna Ports |
4 RP TNC Female |
| Output Power |
30 dBm |
| Power Supply |
12 V |
| Current Dissipation |
0.5 A to 1.2 A |
| Storage Temp |
-4 °F to +167 °F (-20 °C to +75 °C) |
| Working Humidity |
5 % RH to 95 % RH |
| Size |
10.63 in x 7.09 in x 1.06 in (270 mm x 180 mm x 27 mm) |
