| Processor |
Intel Jasper Lake N5100 quad-core (up to 2.8 GHz) |
| Operating System |
Windows 10 or Windows 11 (configurable) |
| RAM |
8 GB DDR (standard) |
| Storage |
128 GB eMMC (standard) |
| Expandable Storage |
MicroSD, TF card up to 512 GB |
| Display |
10.1-inch tempered glass IPS capacitive touchscreen |
| Display Resolution |
1280 px × 800 px |
| Brightness |
700 cd per m² |
| GPU, Graphics |
Intel HD Graphics (Gen 11 LP) |
| Speaker, Microphone |
Built-in Waterproof Speaker (1.5 W); internal mic |
| Keys & Indicators |
Power; Volume +/-; 4 programmable function keys; RGB indicator |
| Network & Cellular |
Wi-Fi 802.11 a b g n ac (2.4 GHz & 5.8 GHz); optional 4G module |
| Bluetooth |
Bluetooth 5.0 (BLE) |
| GNSS |
Neo-7 module GPS, Beidou, GLONASS |
| I/O Interfaces |
USB Type-A 3.0 ×1, DC-IN, RJ45 (10,100,1000 Mbps), RS232 ×1, RS485 ×1 |
| SIM & Card slots |
Nano-SIM ×1; TF card slot ×1 |
| Optional Modules |
4G modem, NFC (NXP300), car charger, Wi-Fi, GPS antennas |
| Power & Battery |
Optional 7.4 V, 1000 mAh Li-Poly emergency battery; standard cable, DC powering |
| Charging |
Direct car charging supported; external adapter, wide-voltage options |
| Environmental Protection |
IP65 (dust-tight and water resistant against sprays) |
| Humidity |
Up to 95% RH non-condensing |
| Drop Resistance |
Designed for vehicle vibration and multiple drops to meet vehicle use profiles |
| ESD Immunity |
± 15 kV (air), ± 8 kV (contact) |
| Operating Temperature |
−4 °F to 140 °F (−20 °C to 60 °C) |
| Storage Temperature |
−22 °F to 158 °F (−30 °C to 70 °C) |
| Dimensions (Product) |
10.41 in × 7.25 in × 0.91 in (264.5 mm × 184.1 mm × 23.0 mm) |
| Weight (Product Only) |
1.838 lb (834g) |
