| Distance |
16.4 ft to 656168 ft (5 m to 200 km) |
| Pulse Width |
5 ns to 20 μs |
| Measurement Time |
User Defined |
| Distance Accuracy |
± (1.64 ft + 0.0001% × Distance + Sampling Resolution) |
| Attenuation Accuracy |
0.005 dB |
| Loss Threshold |
0.001 dB |
| Loss Resolution |
0.001 dB |
| Distance Resolution |
0.098 ft (0.03 m) |
| Sampling Quantity |
128,000 |
| Linearity |
0.05 dB/dB (AE2300), 0.03 dB/dB (AE2300H) |
| Data Storage |
3000 pcs |
| VFL |
10 mW (AE2300 Option), (AE2300H Standard) |
| LCD |
4.3 in, 16:9, 480×272 Dot-Matrix TFT Touch Screen |
| Fiber Adapter |
FC/PC, SC/PC |
| Interface |
USB (Principal and subordinate each), RJ45 |
| Power |
AC/DC Adapter (Input AC 100V to 240V ±10%, Output 12V) |
| Dynamic Range |
24/26/28 dB |
| User-Friendliness |
One-button Testing |
| Use |
Visual Fault Locator |
| Packing |
Exporting Carton |
| Delivery |
Around 7 days |
| OEM ODM |
Acceptable |
| Operating Temperature |
32 °F to 104 °F (0 °C to 40 °C) |
| Dimension |
9.45 in × 5.31 in × 2.75 in (24 cm × 13.5 cm × 7 cm) |
| Weight |
<2.2 lb. (1 kg) |
