| Auto-Off |
Configurable: 5 minutes to 30 minutes |
| Operation Setting |
Supported languages: English, Chinese, Korean, Russian, Italian, French, Polish, Spanish, Japanese, German, Turkish, Portuguese, Czech, etc. |
| Battery |
Built-in 3.7V lithium-ion battery, 6000mAh; Rechargeable: 3-hour charge supports 6 hours of operation |
| Size & Display |
5.4-inch IPS touch screen, 1920 x 1152 resolution |
| UTP Cable Test |
Tests UTP cable connection status; displays results on screen; detects near-end, mid-end, and far-end RJ45 faults; supports shielded cables |
| Length Measurement |
Network cable length measurement up to 1.86 miles (3 km) |
| Optical Power Meter |
Wavelength: 1625 nm, 1550 nm, 1490 nm, 1310 nm, 1300 nm, 850 nm; Measurement range: -70 to +6 dBm |
| Visual Fault Locator |
10mW visual fault locator; 650 nm wavelength; red laser for multi-mode/single-mode fiber testing; test range: 5 miles (8 km) |
| Working Humidity |
30 % to 90 % |
| Working Temperature |
14°F to 122°F (-10°C to 50°C) |
| Dimension |
7.2 in x 4.3 in x 1.4 in (18.3 cm x 11 cm x 3.65 cm) |
| Weight |
0.99 lbs (0.45 kg) |
