| Use |
FTTX |
| Network |
None |
| Wavelength |
1310±20 / 1550±20 nm |
| Laser Adapter |
FC/PC, SC/PC (option) |
| LCD Type |
5 in TFT colorized LCD |
| Measurement Time |
User-defined (smart link), with real-time measurement function |
| Interface |
USB |
| Power |
AC input: 100 to 240V, 600mA, 50 Hz/60Hz DC output: 12.0V, 2A |
| Battery |
Built-in rechargeable Li-ion battery; charging time < 4 hours; working time > 8 hours |
| Data Storage |
3000 items |
| Dynamic Range |
34 / 32 dB |
| Event Dead Zone |
Less than 9.8 ft (< 3 m) |
| Attenuation Dead Zone |
Less than 82 ft (< 25 m) |
| Distance Range |
0.003 to 99.4 miles (5 m to 160 km) |
| Pulse Width |
5 μs to 20 μs |
| Distance Accuracy |
± (3.3 ft + 0.001% x range + sampling resolution) |
| Attenuation Accuracy |
±0.05 dB/dB |
| Loss Limit |
0.01 dB |
| Loss Resolution |
0.001 dB |
| Sampling Resolution |
0.32 ft (0.1 m) |
| Sampling Points |
128000 |
| Relative Humidity |
Less than 80% |
| Storage Temperature |
-4 °F to 158 °F (-20 °C to 70 °C) |
| Operating Temperature |
32 °F to 104 °F (0 °C to 40 °C) |
| Dimension |
12.2 in x 9.1 in x 5.1 in (31 cm x 23 cm x 13 cm) |
| Weight |
Less than 2.2 lbs (< 1 kg) |
