Description
Features
- Adopt IPQ 8072 A chipset solution, Quad core Arm Cortex A 53s CPU
- the main frequency is up to 2.2 GHz, MHZ
- Adopt independent Wi-Fi chip, 2.4G is qcn 5024, 5.8 G is qcn 5054
- 4G rate up to 1147 Mbps, 5.8 G rate up to 2402 Mbps
- 4 G and 5.8 G supports MU-MIMO
- High speed 1 GB DDR4 with 8 MB nor flash and 256 MB EMMC storage
- 1 x WAN, 2 x LAN all 1000 M adaptive network ports
- Support automatic flip (Auto MDI or MDIX)
- Built-in M.2 standard interface
- Can be used to connect 5G mobile communication module
- External standard SIM card interface, support SIM, USIM card
- 5G module power supply is independently controlled by GPIO
- IPQ 8072 with watchdog function, reboot automatically in case of crash
- External high gain omnidirectional antenna
- wireless signal 360 degrees without dead angle
- All LED lights can be turned off by one button
Technical Specifications
| Ethernet Port | 1 x WAN port, 1000 Mbps supports auto flip (Auto MDI, MDIX) Compliant with IEEE 802.3, 802.3 u, 802.ab2 x LAN port, 1000 Mbps support auto flip (Auto MDI, MDIX) Compliant with IEEE 802.3, 802.3 u, 802.ab |
| SIM card Interface | 1 x NANO sim card slot, support SIM, USIM |
| Button | 1 x reset |
| Antennas | 4 x omnidirectional 5 dbi 2.4 G antennas 4 x omnidirectional 5 dbi 5.8 G antennas4 x omnidirectional 5 dbi 5G mobile communication antennas, Compatible with 4G, 3G, 2G band |
| M.2 Interface | Built-in M.2 slot, it supports USB 3.0 bus and can be used to expand 5G module |
| Processor | IPQ 8072 A chipset solution, Quad core Arm Cortex A 53 s CPU, the main frequency is up to 2.2 GHz MHZ |
| 2.4G WIFI chipset | 2.4 G, qcn 5024, IEEE 802.11 ax, n, g, b, maximum speed 1147 Mbps, 4T 4R |
| 5.8G WIFI chipset | 5.8 G, qcn 5054, IEEE 802.11 ax, ac, a, maximum speed 2402 Mbps, 4T 4R |
| Ram | DDR 4 1 GB |
| Flash | Nor Flash 8 MB and 256 MB EMMC |
