| Max. LAN Data Rate |
150 Mbps |
| Wi-Fi Supported Frequency |
2.4 G |
| Standards And Protocols |
Wi-Fi 802.11g, Wi-Fi 802.11b, Wi-Fi 802.11n, Wi-Fi 802.11ac |
| Encryption Type |
WPA2-Enterprise, WPA-Enterprise |
| LAN Ports |
8 x GE electric mouth |
| Wi-Fi Transmission Standard |
802.11b |
| Wired Transfer Rate |
10 Mbps or 100 Mbps |
| WAN Ports |
3 x GE Combo + 1 light |
| Connect |
RJ45 |
| Transmission performance |
9 Mpps to 40 Mpps |
| Machine exchange capacity |
20 Gbps to 80 Gbps |
| Fixed WAN interface |
1 x 10GE optical (compatible with GE optical) +2 x GE Combo |
| SIC slot |
2 |
| 5G |
Supports 5G to SIC service boards |
| Serial auxiliary/console port |
1 x RJ45 Console Serial |
| Size |
1.75 in x 8.68 in x 17.40 in (4.44 cm x 22.04 cm x 44.2 cm) |
| Weight |
10.14 lbs (4.6 kg) |
