| Computing |
CPU: MT7628, RAM: DDR2, 128 MB |
| Wi-Fi Specifications |
Frequency: 2.4 GHz (802.11b or g or n), RX Sensitivity: -95 dBm (Min), TX Power: 20 dBm (Max) |
| Operation Channels |
2.4 GHz: 1 to 13 |
| LoRa Features |
LoRa Card: SX1302 Mini PCIe card, Channels: 8 Channels |
| LoRa Frequency Bands |
Supported Frequencies: EU433, CN470, EU868, US915, AS923, AU915, IN865, KR920 |
| Cellular Module Support |
Supported Module: Quectel EG95-E or EG95-NA (IoT or M2M optimized LTE Cat 4) |
| LTE & WCDMA Frequency Bands |
LTE FDD Bands: B1 or B3 or B7 or B8 or B20 or B28A, WCDMA Bands: B1 or B8 |
| LoRa TX Specifications |
TX Power: 27 dBm (Max) |
| Power Consumption |
12 W |
| Frequency |
2.4 GHz |
| RX Sensitivity |
-139 dBm (Min) |
| Power Supply |
DC 12 V to 1 A |
| Dimension |
6.53 in x 5 in x 1.41 in (16.6 cm x 12.7 cm x 3.6 cm) |
| Operating Temperature |
14 °F to 131 °F (-10 °C to 55 °C) |
| Weight |
10.58 oz (300 g) |
