Description
Features
- Support ISA or PCI or PCIMG industrial baseboard
- Shock-resistant disk drive bay design
- Intel H110 chipset, supports 6 to 9th Gen
- Support up to 64GB memory, Supports SATAIII, mSATA
- Support VGA+ HDMI display interface 2x LAN
- Support 6 x COM, 4 x USB3.0
- Support 1x PCIe 16X，1x PCIe 4x slots
- Flexible mechanical design
Technical Specifications
| Color | Beige |
| OS | Supports Win7, 8, 10 , Linux |
| Material | High-quality high-strength structural steel, with corrosion resistance, impact resistance, wear resistance characteristics |
| Processor System | Support 6 to 9th Gen LGA1151 Core i3 or i5 or i7 processor |
| Chipset | H110 |
| BIOS | 64Mb SPI FLASH |
| Memory | 2x DIMM memory slots supporting DDR4 , supports up to 64GB (Optional configuration) |
| Storage | Support 3 x STAT III, 1x M sata (Optional configuration) |
| Display | Provide VGA + HDMI display interface VGA:1 standard DB15 VGA interface, supports resolution up to 1920 x 1080 at 60Hz HDMI:1 standard HDMI interface, supports resolution up to 4096 x 2304 at 60Hz |
| Network | Onboard 2 intel 10 or 100 or 1000Mb adaptive network cards, using 219v or 211 network card chips |
| Serial Port | Provide 6 x COM Among them COM1 supports RS232 or 485 or 422, COM 2 supports RS232 or 485, COM 3-6 support RS232 |
| USB | 4 x USB3.0 6 x USB2.0 2 x USB2.0 on the front panel |
| Watchdog | Watchdog function, supports 1 to 255 seconds of system restart |
| Expansion Slot | 1 PCIe 16X slot 1 PCIe 4X slot 5 PCI slots |
| GPIO | Provide a 2x 5-pin 2.54mm GPIO pin interface, Supporting 4 inputs and 4 outputs |
| Audio | Realtek ALC662; Supports Line-out and Mic-in |
| DVD | DVD or DVDRW |
| Power Requirement | Standard ATX 24pin power supply,250W, 300W, 400W, 500W, Redundant power supply (optional) |
| Operating Humidity | 5% to 95%, |
| Operating Temperature | 32°F to 140°F ( 0 to 60 °C ) |
| Dimensions | 18.90 x 16.93 x 6.89 inches (480mm x 430mm x 175 mm) |
