Description
Features
- High Temperature Resistance
Low Temperature Resistance - Anti Statics
- Surge Resistance
- Anti-EMC electromagnetic interference
- Analog Input
- Digital Input Alarm
- Do Relay Output
- Temperature and humidity Alarm
- RS485, Modbus Slave Alarm
- SMS / Phone Alarm
- S275 Modbus Internal Calculation Function
- Data Retransmission function
Technical Specifications
| Specification | Details |
| Chipset | IIOT |
| Application | Industrial or IoT Monitoring |
| Type | Cellular Module |
| Power Supply | 9 to 36V DC |
| Power Consumption | 12V at 50mA |
| Mini USB for Parameter Configuration | 1 port |
| RS485 | 1 port |
| Baud Rate | 1200bps to 115200bps |
| Data Bit | 8 |
| Parity Bit | None, Even, Odd |
| Stop Bit | 1, 2 |
| Digital Inputs (DI) | 8 ports |
| Analog Inputs | 6 ports |
| Digital Outputs (DO) | 4 ports |
| SIM Card Slot | 1 port |
| Temperature & Humidity Port | 1 port |
| Boolean | 64 |
| 16-bit | 64 |
| Operating Temperature | 32 °F to 104 °F (0 °C to 40 °C) |
| Product Weight | 2.2 lb (1 kg) |
| Size / Dimension | 1.50 in x 0.47 in (38 mm x 12 mm) |
