Description
Technical Specifications
| CPU | Onboard 5th generation Core U-Processor, Mobile Intel Pentium
Celeron series CPU |
| RAM | 2 x 204Pin DDR3L SO-DIMM memory slots, support 1333 or 1600 MHz DDR3L system memory, the maximum can be expanded to 16 GB |
| Operating System | Windows 10, Windows 8, Windows 7, Android, Linux |
| Display Output | CRT, HDMI 1.4a display output function |
| Storage | 1 x 7 + 15Pin SATA interface ((6.35 cm) 2.5-inch SATA hard drive)
1 x mSATA function slot 32G or 64G or 128G or 256G SSD |
| USB | 6 x USB 2.0 high-speed interface
2 x USB 3.0 high-speed interface, internally provide 1 x USB 2.0 Wafer |
| Serial Port (COM) | 1 x RS-232 standard DB9 serial port (COM1)
1 x RS-232 or RS-422 or RS-485 DB9 serial port (COM2) |
| Ethernet (LAN) | 2 x 10 or 100 or 1000Mbs network interface (WGI211AT), support network boot (PXE), wake-up on LAN (WOL) |
| Expansion Slot | 1 Mini PCIE (can choose to support Mini PCIE X1 device or 4G SIM card device) |
| Audio Port | 1 x Ø3.5 PhoneJack audio output interface
1 x Ø3.5 PhoneJack MIC interface |
| Resolution | 1920 x 1200 |
| Other Functions | 1 x LPT
1 x 16-way DIO 1 x SIM card slot (optional) 1 x PS or 2 mouse or keyboard interface, watchdog timer and other functions |
| Power Supply | DC 12V to 24V power input |
| Shell Composition | Aluminum alloy die-casting shell |
| Color | Iron gray |
| Relative Humidity | 5% RH to 95% RH (non-condensed state) |
| Working Environment | 14°F to 140°F (-10°C to 60°C) |
| Storage Environment | -40°F to 176°F (-40°C to 80°C) |
| Size | 9.05 in (W) x 8.66 in (H) x 2.00 in (D)
(230 mm (W) x 220 mm (H) x 51mm (D)) |
