| Use |
Industrial |
| Hard Drive Type |
SSD + HDD |
| Video Memory Type |
With the main memory |
| Processor Core |
Quad Core |
| Operating System |
Win 10 |
| Processor Type |
Inter Core I5 |
| Graphics Card Chip Set |
Integrated Card |
| HDD Rotation speed |
SSD |
| Processor Series |
Intel Core I5-8250U |
| Video Memory |
2GB |
| Video Card |
Intel UHD Graphics 620 |
| After Sales Service |
Return and Replacement |
| Plug Type |
US, JP, CN, AU, UK, EU |
| Power |
52 W |
| RAM type |
DDR4 |
| Mouse and keyboard |
NO |
| Private Mold |
Yes |
| CPU |
Intel Core i5-8250U (6M Cache, 4 Cores 8 Threads, Base Frequency 1.60 GHz Turbo Frequency 3.40 GHz) |
| TDP |
15W |
| CPU Lithography |
14 nm |
| Memory Types |
2 X DDR4 SO-DIMM 260 pin |
| Memory Channels |
Dual Channels |
| ECC Memory |
Don’t Support |
| m.2 SSD |
1 X M.2 2280 M KEY PCIE3.0 |
| SATA |
1 X SATA 3.0 Slot for (6.3 cm) 2.5 in HDD or SSD |
| mSATA |
1 X mSATA slot |
| Processor Graphics |
Intel UHD Graphics 620 |
| HD |
1 X HD 4096 X 2160 at 60 Hz(4K) |
| EDP |
1 X ED 4096 X 2160 at 60 Hz(4K) |
| DP |
1 X DP 4096 X 2160 at 60 Hz(4K) |
| Adapter Output |
DC 12 V or 6 A |
| Adaptor Input |
AC 110 V to 240 V, 50 HZ or 60 HZ |
| Consumption |
52 W |
| Auto Power on |
Support Auto Power On Function |
| USB Port |
4 X USB 3.0 port,4 X USB 2.0 port |
| Audio |
1 X 0.1 in (3.5 mm) MIC in & SPK out |
| Video |
HD 4096 X 2160 at 60 Hz + EDP 4096 X 2160 at 60 Hz + DP 4096 X 2160 at 60 Hz 3 Display Output |
| Audio Cards |
Realtek ALC 662 or 897 |
| M.2 |
1 X M.2 E KEY 2230 |
| LPT |
1 X LPT(line print terminal) |
| WIFI |
Inside Wifi & Bluetooth Combo |
| System |
Support Windows 10 or 11, Linux |
| BIOS |
Support TPM2.0,RAID,AUTO POWER ON, Wake On LAN, Watchdog, PXE or IPXE |
| SIM |
1 X SIM slot |
| MPCIE |
1 X MPCIE, Support 4G or Wifi module |
| Case Material |
Full Brushed Aluminum Alloy |
| GPU |
Intel UHD Graphics 620 |
| Max Memory Size |
64 GB |
| Com port |
6 X RS232 Com port |
| Display Port |
HD + EDP + DP |
| USB Port |
4 X USB 3.0 port,4 X USB 2.0 port |
| LAN Port |
2 X RJ45 LAN Gigabit Ethernet Controller |
| Work environment |
(-10 ℃ to 60 ℃) 14 °F to140 °F , 30 % to 90 % Humidity |
| Dimensions |
9.3 in X 7.1 in X 2.0 in (238 mm X 182 mm X 52 mm) |
| Weight |
3.3 lbs (1.5 kg) |
